Space for precision work and passion for technology

What makes working at SCHLEIFRING so special? We develop and manufacture high-tech components with which we constantly extend the limits of technical feasibility. This is not only challenging, it also sets trends for the future.

Current vacancies

Two employees work together in a good mood on an electronic component in assembly.

Hand holding a small round clock or stopwatch over newspaper pages.

At a glance: tasks and fields of activity in the SCHLEIFRING production

Machines: In the field of additive manufacturing, we work with four different printing processes. For this purpose, we have eight printers at our disposal.

Materials: We process materials such as PA6 / PA11 / PA12GB (Polyamide), TPU, ABS, ceramics, aluminum and copper.

Workpieces: A third of the parts manufactured are required for the development of new products. The other two thirds are used in our slip rings: for example, in the form of complex brackets, covers, fiber guides, housings or production resources.

Current vacancies

Turning

Machines:

One conventional lathe (without program / without automation)
Six NC cycle lathes (with program / without automation)
Two CNC turning/milling machines (with program and automatic tool changing / complete machining)

Materials: We are able to process and machine all aluminum alloys, stainless steels, alloy and non-alloy steels, non-ferrous metals (brass, copper, silver) as well as technical plastics.

Workpieces: We manufacture prototypes, pilot runs, small batches as well as series with medium-sized batches. The machining spectrum is large and ranges from the smallest machining size of Ø 0.8 x 10 mm to a maximum of Ø 880 x 1,460 mm.

Milling

Machines:

One conventional FP4 NC milling machine (programming on the machine)
Two five-axis CNC milling machines with pallet storage systems and external set-up stations (with program and automatic tool changing)
While machining one batch, the machines can be set up for the next batch by means of the external set-up station and the pallet storage system. This increases the spindle run time. The challenge when producing small batches is to optimize the set-up process.

Materials and workpieces: see Turning

Current vacancies

Goal: We guarantee absolute precision – to the nearest μm. To achieve this, we supplement the tactile quality control by means of 3D coordinate measurement with surface roughness measurement and a visual inspection process. Because only perfect interaction between man and machine enables precision parts to be produced to the highest level of quality.

Machines:

One coordinate measuring machine – with integrated precision rotary table. Accuracy: 1μm +; measuring range: Ø 1100 x 1100 x 600 mm; additional equipment: integrated precision rotary table; software: Calypso
Three manually operated coordinate measuring systems: Keyence XM5000; Scan Max; Tesa height gauge
Six conventional measuring workstations

Inspection process: We document and sample prototypes and individual parts as well as complete series. For the final acceptance of a series, we first of all create an initial-sample test report on the actual/target state so that we can give the green light for series production. In addition, all parts are subjected to a visual inspection for damage, cracks and scratches. Most parts run through the quality control process several times in order to be able to react in good time during an intermediate inspection and during the final inspection.

Current vacancies

Workpieces: Modules are cylindrical parts with diameters ranging from 10 mm to approx. 800 mm made up of individual rings that are embedded in plastic in order to transmit data, signals and currents. The module production manufactures the centerpiece of ever slip ring: the module.

Process: The machining is performed using synthetic and natural diamonds in order to produce a flawless, mirror-like surface. In the final processing step, the module is refined with a layer of gold in order to improve the transmission quality and achieve a longer service life. As the module is essential for the slip ring’s function, we subject every module to a 100% inspection.

Materials:

Plastic
Brass
Silver
Gold
Copper

Production areas:

Resistance spot welding
Foundry
Turning shop
Contact check
Optical module inspection

Current vacancies

Goal: The goal is to develop products from the prototypes to qualified series units. High-precision slip rings are produced in the assembly areas through teamwork and in compliance with all process instructions and standards.

Spectrum of tasks: The spectrum of tasks ranges from the pre- and final assembly of electromechanical components to electrical testing:

More than 220 different variants
Up to 3,000 individual parts
More than 1,000 soldered and crimped connections
Assembly time of up to eight weeks
Duration of inspection and customer approvals of up to two weeks

Goal: Production of high-tech products through precision, reliability and a sure hand.

Current vacancies

Goal: In this production area we perform electrical testing on the product in order to verify the characteristics specified in the inspection plan. Subsequently, product approval is also performed here with the customers.

Procedure: After the actual testing, the results are documented in such a way that they are clearly comprehensible. If faults are detected in the product, suitable corrective measures are initiated.

Current vacancies

Spectrum of tasks: Process engineering specialists perform tasks in all areas of production:

Analysis of production processes and determination of optimization potential
Development of solutions together with the relevant departments (production, design, development, quality assurance)
Implementation of the solutions developed (project management, creation of tender documents / target specification documents, search for and selection of suppliers, conduction of tests, documentation, …)
Introduction of and training in new processes and systems

Current vacancies

Work-preparation – Spectrum of tasks:

Creation of manufacturing bills of material on the basis of the engineering bills of material in SAP
Creation of work schedules in SAP, detailed work schedules and process instructions
Creation of raw materials and fixtures
Changing material types in SAP (in-house/third-party manufacturing)
Clarification, planning and implementation of rework on production parts
Feedback regarding fundamental production problems to the design and development departments
Measurement of production times in order to adapt the work schedules
Development of new processes and aids in order to optimize production

Production planning – Spectrum of tasks:

Scheduling of customer orders taking into account the present capacity utilization and procurement situation
Responsibility for resource scheduling and planning for individual parts, assemblies and finished goods
Development and implementation of logistically necessary measures during new projects involving a large number of new parts
Regular capacity coordination with the production areas
Ensuring the supply of material in conjunction with the optimization of availability and inventory turnover
Creation of delivery schedules in cooperation with sales and project management
Continuous improvement of logistics processes as well as flexibility in production

Operative purchasing – Spectrum of tasks:

Ordering all relevant purchased parts for production
Tracking deadlines / obtaining order confirmations
Escalation in the event of missing parts in cooperation with production planning and the strategic purchasing department

Warehouse/logistics – Spectrum of tasks:

Goods receipt/shipping with regard to finished parts, purchased parts and extended workbenches
Ensuring on-schedule supply and in-house transport for production and assembly

Current vacancies

We promote personal further development:

Row of modern drilling machines in a workshop.

Two young men working together on a metal part in a workshop.

Every movement is perfect. You master your work and achieve results with the highest level of quality and precision. To enable you to achieve this level of perfection quickly and unerringly, in the SCHLEIFRING Academy we offer you practice-oriented training courses and professional qualifications.

Production training courses

Close-up view of a precision lathe in a workshop.

You learn how to interpret and implement process instructions. Afterwards, you will know which work steps are to be performed in which sequence, with which tools or aids, and how to meet quality and safety standards.

In this module you deepen your knowledge of electrical test methods in order to guarantee the function and safety of cables.

Roller bearings connect two parts that move relative to each other and thus enable rotational movements. They also reduce friction and absorb forces. You learn how to correctly install roller bearings during an external training course.

Slip rings are often exposed to extreme environmental conditions. Sealing elements are thus critical for the quality and durability of our products. You learn everything there is to know about their installation in an external training course.

Using the latest adhesive technology, we permanently and safely connect our parts without causing mechanical damage. You learn how this works in this training module.

Soldering technology, especially soft soldering, plays a central role in our assembly. That is why we provide in-house training in soft soldering within the scope of a three-day training course. This is followed by a three-day external training course that ends with an examination and certification.

Insights into the production

Taking on responsibility means that you shape the future. As an international technology company, SCHLEIFRING relies on durable products, resource-conserving processes and a conscious team culture. Our goal: Innovation in harmony with the environment and society in general.

Sascha Berwanger

Head of module production

Sascha Berwanger

Head of module production

Being a manager is a life's work, a 100% commitment every day. You are no longer only responsible for yourself, but rather for the welfare of the company and the employees for whom you are responsible.

Cristina Königseder

Precision mechanic

Cristina Königseder

Precision mechanic

Franz Weigl

Industrial mechanic

Franz Weigl

Industrial mechanic

Industries in which we operate

A passenger plane flies high above the clouds.

In the aerospace sector, slip ring designs are subject to extreme conditions. The requirements on precision and technical reliability are thus correspondingly high. As a manufacturer, we develop bespoke slip rings together with our customers that meet these requirements.

Learn more

A modern MRI machine in a bright, white examination room.

To ensure progress in the medical sector, imaging techniques such as computer tomography are indispensable. Modern CT scanners generate huge amounts of data in order to produce high-resolution images. These are transmitted contactlessly, quickly and reliably by our CT slip rings designed specifically for this purpose – at up to 340 gigabits per second.

Learn more

Military radar with several large antennas against a blue sky.

The more information, the higher the level of safety. This is the formula for success for slip rings in radar and reconnaissance systems, 360° surveillance systems and baggage scanners. We put this into practice by incorporating an increasing amount of technology in the same installation space in order to achieve improved performance and higher transmission rates.

Learn more

Two large wind turbines stand in green fields under a blue sky.

Renewable energy generated by wind is one of the key components of the global energy transition. To ensure the efficiency of on- and offshore installations, quickly and precisely adjustable rotor blades are essential. Power and signals for this purpose are reliably transmitted by our high-precision wind turbine slip rings.

Learn more

Water bottles on a conveyor belt for bottling.

Industry’s requirements on slip rings and rotary joints are as wide-ranging as the processes themselves. Together with our customers, we develop suitable bespoke transmission solutions: whether contactless and maintenance-free, optimized for confined installation spaces, or contacting and inexpensive. It’s the goal that counts.

Learn more

Ready for the next step?

Start you career at SCHLEIFRING! We offer you exciting career prospects and accompany you on your career path. Discover how you can grow with us – we support you during every step of your journey.

Current vacancies

Employee sits smiling at his workplace in electronics production.

Locations

SCHLEIFRING has built up a strategic network of production plants and sales and service subsidiaries all round the world. This enables us to be as close as possible to our customers and to help them quickly, no matter what they need.
